Maxi-Corn mulcher for tractor
The MAXI-CORN mulcher for tractor is specially designed to shred all types of crops, grass, low scrub and branches of up to 6 cm in diameter.
Features:
Robustness
Innovation
Flexibility
Durability
Maxi-Corn mulcher for tractor description:
The MAXI-CORN mulcher for tractor is specially designed to shred all types of crops, grass, low scrub and branches of up to 6 cm in diameter. Low power absorption. Roller or wheels for height adjustment. Hydraulic or manually controlled hinged hood. Very solid and sturdily built. Uniform shredding.
Maxi-Corn mulcher for tractor features:
- SWING HAMMER ROTOR WITH SPECIAL DISTRIBUTION AND LOW POWER ABSORPTION
- ROTOR Ø 500 mm.
- ROTOR TUBE 220X10 mm.
- AXLE DIAMETER Ø 60 mm.
- TWIN CHASSIS
- STEEL BEARING SHELLS
- ROTOR BEARINGS WITH DOUBLE ROW OF ROLLERS
- V-BELT WITH KEVLAR FIBRE
- FLOATING WORK SYSTEM
- HAMMERS WITH LOW POWER ABSORPTION
- HAMMER SCREWS MADE OF 12.9 STEEL
- GROUP WITH FREE WHEEL
- TRANSMISSION INCLUDED
Maxi-Corn mulcher for tractor models:
| Working width | Overall width | Weight Kg. | Hammers | Belts | HP (indicative) | R.P.M. | Shaft |
|---|---|---|---|---|---|---|---|
| 4800 | 5190 | 2480 | 48 | 8 | 120-150 | 1000 | 1″ 3/8 Z-6 |
| 5200 | 5590 | 2640 | 48 | 10 | 140-170 | 1000 | 1″ 3/8 Z-6 |
| 5600 | 5990 | 2800 | 52 | 10 | 150-180 | 1000 | 1″ 3/8 Z-6 |
Maxi-Corn mulcher for tractor accesories:
Front chain set
Third hydraulic point
| Measures | Stretch work | Transport folding |
|---|---|---|
| Widht | 5190/5590/5990 | 2550 |
| Height | 1320 | 3010/3210/3410 |
| Bottom | 1800 | 1800 |
