Pocket Reversible Mulcher
The POCKET REVERSIBLE mulcher is specially designed to shred all kinds of pruned branches from trees such as almond, citrus and olive.
Features:
Robustness
Innovation
Flexibility
Durability
Pocket Reversible Mulcher description:
The POCKET REVERSIBLE mulcher is specially designed to shred all kinds of pruned branches from trees such as almond, citrus and olive. The mulcher is designed to operate in both forward and reverse drive, with a double pick-up feeder to pass the branches into the shredding chamber. It is available with two types of rotors: with hammers or blades. The system of interchangeable PICURSA grids allows the fineness of shredding and the shredding speed to be selected. Low power absorption. Roller or wheels for height adjustment. Hinged hood offers easy access to the hammers. Very solid and sturdily built. Uniform shredding.
Pocket Reversible Mulcher features:
- HAMMER OR BLADE ROTOR, LOW POWER ABSORPTION
- ROTOR Ø 500 mm.
- ROTOR TUBE 220X10 mm.
- AXLE DIAMETER Ø 60 mm.
- METAL CHASSIS WITH HIGH ELASTIC LIMIT
- STEEL BEARINGS SHELLS
- ROTOR BEARINGS WITH DOUBLE ROW OF ROLLERS
- V-BELT WITH KEVLAR FIBRES
- HAMMER SCREWS MADE OF 12.9 STEEL
- FLOATING WORK SYSTEM
- FIXED WHEELS FOR HEIGHT CONTROL
- FREE WHEEL TRANSMISSION INCLUDED
Pocket Reversible Mulcher models:
| Working width | Total width | Weight Kg. | Hammers | V-Belt | HP (indicative) | R.P.M. | Axle |
|---|---|---|---|---|---|---|---|
| 1600 | 1900 | 1340 | 16 | 4 | 70-90 | 540-1000 | 1″3/8 Z-6 |
| 1800 | 2100 | 1460 | 16 | 5 | 80-110 | 540-1000 | 1″3/8 Z-6 |
| 2000 | 2300 | 1580 | 20 | 5 | 90-120 | 540-1000 | 1″3/8 Z-6 |
| Working width | Total width | Weight Kg. | Blades | V-Belt | HP (indicative) | R.P.M | Axle |
|---|---|---|---|---|---|---|---|
| 1600 | 1900 | 1380 | 64 | 4 | 70-90 | 540-1000 | 1″3/8 Z-6 |
| 1800 | 2100 | 1500 | 64 | 5 | 80-110 | 540-1000 | 1″3/8 Z-6 |
| 2000 | 2300 | 1620 | 80 | 5 | 90-120 | 540-1000 | 1″3/8 Z-6 |
Pocket Reversible Mulcher accesories:
Plus group with free wheel
Plus group reversible
Flow adjuster
Interchangeable grate set
Pocket nail pick-up kit
