trituradora de brazo RETRO BOXING
The MARTILLO FIJO RETRO BOXING boom mulcher is specially designed to shred branches, small trees, tree stumps and debris from tree-felling.
Features:
Robustness
Innovation
Flexibility
Durability
trituradora de brazo RETRO BOXING description:
The MARTILLO FIJO RETRO BOXING boom mulcher is specially designed to shred branches, small trees, tree stumps and debris from tree-felling. Its design enables it to be mounted onto any model of excavator or backhoe and comes with a hydraulic motor that depends on the litres of oilflow and pressure of each machine. It is equipped with special alloy hammers with hard metal tips that make them more resistant and harder-wearing. The special positioning of the hammers on the rotor produces very fine shredding and the shredded material is evenly spread over the terrain. Skid runners for height adjustment. Manually controlled hinged hood. Very solid and sturdily built.
trituradora de brazo RETRO BOXING features:
- FIXED HAMMER ROTOR WITH SPIRAL DISTRIBUTION, LOW POWER
ABSORPTION - ROTOR Ø 440 mm.
- ROTOR TUBE 200 X 20 mm.
- AXLE DIAMETER Ø 75 mm.
- CHASSIS HIGH ELASTIC LIMIT
- STEEL IRON BEARING SHELLS
- ROTOR BEARINGS WITH DOUBLE ROW OF ROLLERS
- V-BELTS WITH KEVLAR FIBRE
- HAMMER SUPPORT MADE OF ANTI-WEAR MATERIAL
- HAMMER SCREWS MADE OF 12.9 STEEL
- FRONT CHAIN SET
- PISTON HYDRAULIC MOTOR ANGULAR Pmax=350 bar.
- BY-PASS SYSTEM INCLUDED
- HOSES 4 MAYAS UP TO HAMMER INSTALLATION INCLUDED.
trituradora de brazo RETRO BOXING models:
| Working width | Mounted mulcher weight | Litres | Total width | Weight Kg. | Hammers | V-Belts |
|---|---|---|---|---|---|---|
| 600 | 8-12 Tn. | 80-200 | 900 | 520 | 12 | 4 |
| 800 | 10-14 Tn. | 90-200 | 1100 | 580 | 16 | 4 |
| 1000 | 10-14 Tn. | 100-200 | 1300 | 670 | 20 | 4 |
| 1200 | 12-20 Tn. | 120-200 | 1500 | 700 | 24 | 5 |
| 1500 | 10-14 Tn. | 120-200 | 1800 | 780 | 28 | 5 |
trituradora de brazo RETRO BOXING accesories:
Quick custom-built hitch (weight ≃160 kg.)
Support ryper (weight ≃50 kg.)
Quick custom-built with support hitch
